General Sizing Notes
For Nozzle diameter add .250” to the diameter of the parts to be positioned in the nozzle. Example: For material diameter .100” the nozzle diameter will be .350”
For nozzle width, this is based on the process performed. Example: for an overlap joint the nozzle width will equal the overlap length. For laminations we recommend maximum width (.500”)
Width (.25” Min .625 max .25 min) and diameter (.375 Min. 1.0” max .) machined to customer specifications
Minimum Width: .040″ / Maximum Width: .500″
Minimum Diameter: .040″ / Maximum Width: .500″
